Magdrive and mechanical seal industrial pumps
Horizontal and vertical centrifugal pumps

STN series single-stage magnetic drive centrifugal pumps are the close-coupled type made of engineering plastic (PP - GF or PVDF)

STN series single-stage magnetic drive centrifugal pumps are the close-coupled type made of engineering plastic (PP - GF or ETFE)

The new ETN series of: single-stage magnetic drive centrifugal pumps connects directly to a B5 motor.

UTN-BL are horizontal single-stage magnetic drive centrifugal pumps of the latest generation. Designed for direct connection to a B5 motor, they are extremely compact and silent

UTN-L are heavy-duty horizontal single-stage magnetic drive centrifugal pumps of the latest generation. Their design is fully compliant with standards DIN 24256 and ISO 2858.

ETS is a new type of close-coupled single-stage magnetic drive centrifugal pump. Metal components are produced by precision casting.

UTS-B are single-stage magnetic drive centrifugal pumps. Despite being the close-coupled type, they meet the requirements of standards DIN 24256 and ISO 2858.

UTS are single-stage magnetic drive centrifugal pumps. Of the horizontal type, installed on a common baseplate with the drive, they meet the requirements of standards DIN 24256 and ISO 2858.

Resin and steel magnetic drive pumpsMagnetic drive pumps made from engineering plastics (PP, GF, PVDF or ECTFE in stainless steel or in special alloys by precision casting. for transferring corrosive, toxic, filthy, radioactive, sterile or flammable liquids

UCN-L: horizontal centrifugal transfer pumps with conventional mechanical sealing system and fully compliant with standards DIN 24256 and ISO 2858.

UCN-BL: horizontal centrifugal transfer pumps with conventional mechanical sealing system. Designed for direct connection to a B5 motor, they are extremely compact and silent. Inlet and outlet port dimensions meet the requirements of standards DIN 24256 and ISO 2858.

CCN: plastic single-stage horizontal centrifugal pumps with conventional mechanical sealing system. Connected to the driving part by means of a spacer coupling (back pull-out version) and installed on a common baseplate, their design is fully compliant with standards DIN 24256 and ISO 2858.

UCS: metallic horizontal centrifugal transfer pumps with conventional mechanical sealing system. Connected to the driving part by means of a spacer coupling (back pull-out version) and installed on a common baseplate, their design is fully compliant with standards DIN 24256 and ISO 2858.

UCS-B: metallic horizontal centrifugal transfer pumps with conventional mechanical sealing system. Closed, open or open vortex impeller with reduced overhang and tapered stuffing box with abrasion-resistant flow-regulating baffles.

Resin and metallic centrifugal pumps with conventional mechanical sealing systemHorizontal centrifugal pumps corrosive liquids, slurry, liquids containing crystals, dirty liquids, effluents and chemical wastewater.

HTN: plastic single-stage magnetic drive regenerative pumps for high-density liquids. The silicon carbide version can handle particularly aggressive liquids.

HTS: metallic single-stage magnetic-drive regenerative pumps offering possibility of pumping liquids containing up to 20% gas.

Resin and metal magnetic drive regenerative pumps Close-coupled single-stage magnetic drive regenerative pumps. In the plastic version, the pump casing is made from one-piece machined thermoplastic and in the metallic version, the components are produced by precision casting.

CVN: vertical-shaft centrifugal pumps. These pumps are available in the standard versions with lip-seal system or liquid seal to prevent the outflow of rising vapours and gases.

CVN-LD: vertical-shaft centrifugal pumps built from PP or PVDF thermoplastic material. Completely disassemblable.

Vertical centrifugal pumps in resinVertical-shaft centrifugal pumps built from PP or PVDF thermoplastic material. These pumps are available in the standard versions with lip-seal system or liquid seal to prevent the outflow of rising vapours and gases.

STN-A: Plastic self-priming magnetic-drive transfer pumps built from corrosion-resistant plastic. Priming chamber: PP, PVDF or PVC.

ETN-A: self-priming magnetic-drive pumps built from corrosion-resistant plastic. Priming chamber: PP, PVDF or PVC.

ETS-A: AISI 316L steel self-priming magnetic-drive pumps. Priming chamber: AISI 316L steel.

ETN-SP: close-coupled self-priming magdrive pumps

STN-SP: close-coupled self-priming magdrive pumps

Resin and metal self-priming magnetic drive pumpsSelf-priming magnetic-drive transfer pumps made from anticorrosion plastic material or of AISI 316L steel for acids, bases and solvents. Motor sizes range from 1.5 to 7.5 kW at 2900 RPM. Priming chamber: AISI 316L steel. Suction and discharge ports DN 32 x DN 32 or DN 50 x DN 50.

E 492 wattmetric relay: multirange, 2 thresholds with direct insertion up to 7A.

W09 wattmetric relay with RS 485 connection to monitoring PC

Wattmetric relaysRelays for measuring and displaying active power

E 347: low voltage current transformer without primary

TR6 resistance thermometer for industrial applications

A303 phase detectors: Based on amperometric detection, this device is not affected by motor-generated back Emf voltage nor by the network''s supply frequency..

Current transformer
Amperometric detector
Resistance thermometer
